Mantar Rack 19" 1U fiber optic patch panel 12x SC Simplex

Mantar Rack 19" 1U fiber optic patch panel 12x SC Simplex

Produttore: Mantar

Codice prodotto: MANTAR-PS-191U12XSXS

Numero di catalogo: 9994

Garanzia (mesi):

Prezzo

24,58 €

30,23 € IVA inclusa

favoriteLista dei desideri

Descrizione

Rack 19" fiber optic patch panel

The offered product is a patch panel designed for installation in a 19" rack. It has a height of 1U and a depth of 212 mm. It is made of 1 mm thick steel and painted in light gray RAL7035.

12x SC Simplex panel

The front panel is designed to accommodate 12 SC Simplex or LC Duplex adapters. Inside the patch panel, you'll find space for a splice tray and appropriate knockouts for securing excess cable using zip ties. Use trays that have a screw hole for mounting. At the back, there are four openings for cable management, two of which are factory-sealed with grommets.

Fixed Patch Panel

The product does not have rails and is intended for permanent installation in a 19" rack. During operation, the patch panel must be completely unscrewed and removed from the rack, as there is no option to slide out the tray.

Specifications

Mantar PS 19" 1U 12xSX st
Standard	Rack 19"
Front panel	12 slots for SC Simplex / LC Duplex adapters
Height	1U
Width	19"
Depth	212 mm
Weight	3 kg
Plate thickness	1 mm
Colour	RAL7035 light gray
