Solarix SXKD-7A-1200-SSTP-LSOH SSTP cat. 7A LSZH Cca-s1,d1,a1 500m

Solarix SXKD-7A-1200-SSTP-LSOH SSTP cat. 7A LSZH Cca-s1,d1,a1 500m

Produttore: Solarix

Codice prodotto: SOL-SXKD-7A-12SSTPLS

Numero di catalogo: 7731

Garanzia (mesi):

Product on demand

Prezzo

408,62 €

502,60 € IVA inclusa

favoriteLista dei desideri

Descrizione

Installation Cable Solarix Category 7A SSTP LSOH Cca s1 d1 a1 1,200 MHz

These Solarix double shielded installation cables comply with the most stringent structured cabling specifications. They easily exceed the requirements specified in the ISO/IEC 11801 and EN 50173 standards for Category 7A/Class FA cables. Selected design of these cables goes hand-in-hand with the best quality which, with strictly controlled production, guarantees the highest performance. The Solarix Category 7A installation cables are produced in S-STP configuration and are tested up to 1,200 MHz. Their excellent performance ensures full compatibility with all new high-speed data protocols, such as 10GBASE-T. Foamed PE insulated conductors have the pairs shielded by aluminium foil and copper braid. Sheath material is supported by fire retardant, low smoke, halogen free, and CPR rated compounds – i.e. LSOH (reaction to fire Cca s1 d1 a1) and LSOHFR (reaction to fire B2ca s1 d1 a1).

Specification:

SXKD-7-SSTP-LSOHFR
LSOH Sheath	Reaction to fire Cca s1 d1 a1
Applicable Standards	iSo/ieC 11801, ieC 61156-5, eN 50173-1, eN 50173-2, eN 50288-9-1
Conductor Type and Size	Bare copper wire 0.58 mm ± 0.005 mm
Insulation	Skin-foam-skin PE
Wire Diameter with Insulation	1,35 mm
Cable Diameter	7,8 mm
Weight	59 kg/km
Colour	Orange RAL 2003
NVP	79%
Propagation delay	480 ns/100 m
Delay skew	≤ 25 ns/100 m
Storage Temperature	-20 to +60 °C
Operation Temperature	-20 to +60 °C
Installation Temperature	0 to +50 °C

f (MHz)	Attentuation (dB/100m)	NEXT (dB)	PSNEXT (dB)	Prop. delay (ns/100m)	ACR-F (dB/100m)	PSACR-F (dB/100m)	Return loss (dB)
Installation Cables Transmission Characteristics (at 20°C)
1	1,96	101,31	98,99	479,69	100,33	97,29	32,15
4	3,55	99,51	97,53	462,20	97,74	94,19	34,86
10	5,49	98,28	96,15	455,77	95,54	92,37	40,24
16	7,01	98,32	95,32	453,46	94,81	91,49	39,79
20	7,91	98,90	95,96	452,53	94,95	91,63	42,29
25	8,92	97,99	95,49	451,71	93,53	91,75	41,44
31,25	10,05	102,41	99,82	450,97	97,39	94,81	41,75
62,5	14,38	99,54	97,18	449,14	92,35	89,47	36,67
100	18,24	98,38	96,39	448,21	89,26	86,53	37,54
200	25,99	96,46	94,12	447,18	83,47	80,83	33,34
250	29,18	97,03	95,54	446,92	82,44	79,83	37,69
300	32,09	93,29	91,28	446,73	77,25	94,33	29,27
400	37,27	85,50	83,70	446,46	66,87	62,98	30,36
500	41,88	83,76	81,54	446,27	62,82	59,76	27,87
600	45,96	84,49	81,92	446,07	61,51	59,50	25,62
1000	60,09	81,45	78,85	444,93	51,41	49,07	22,33
1200	61,29	80,80	77,69	444,92	50,16	47,95	20,30
